Hohan N7G Series ZZ1315V3666F1 Cargo truck chassis
- Release time：
- Source：Sinotruk HOWO
This vehicle is a new generation of high-end heavy truck product newly developed by SINOTRUK using MAN core assembly technology. It is a leader of lightweight products. Its excellent power, stable and reliable performance, economy and comfort reach the international level. Its safety, reliability and intelligence level are in line with international standards. There are several personalized configuration options.
| Weight Parameter | Curb Mass (kg) | 8900 | |
| Full Loaded Mass (kg) | 31000 | ||
| Rated Towing Mass (kg) | / | ||
| Dimension Parameter | External Size | Length (mm) | 8650,9075,9225,9900 |
| Width (mm) | 2550 | ||
| Height (mm) | 3115 | ||
| Wheel Base (mm) | 1800+3050+1350,1800+3025+1400,1800+3200+1350,1800+3175+1400,1800+3600+1350,1800+3575+1400 | ||
| Min. Ground Clearance (mm) | 267 | ||
| Performance Parameter | Max. Speed (km/h) | 82 | |
| Economic Speed (km/h) | 40～70 | ||
| Max. Grade Ability (%) | 35 | ||
| Min. Turning Diameter (m) | 21，22.9 | ||
| Engine | Model | MC07.31-60，MC07.34-60 MC09.35-60，MC09.35B-60 MC09.38-60，MC11.40-60 MC11.44-60，WP8.350E61 WP10H400E62 |
| Net Power (kW)/Speed (r/min) | ||
| Max. Torque (Nm)/Speed (r/min) | 1230/1200～1800,1250/1200～1800 1660/1100～1400，1510/1100～1400 1760/1100～1400，1907/1000～1400 2107/1000～1400,1400/1200～1600 1900/1200～1300 | |
| Transmission | HW19710L | |
| Clutch（mm） | φ430 | |
| Rear Axle Type | MAT16ZG | |
| Rear Axle Ratio | 4.8（可选5.73） | |
| Fuel Tank (L) | 300 | |
| Frame Section（mm） | 300×80×（8+5） | |
| Suspension (Front/Rear Spring) | 4/4/-,4/4/5,4/4/12,8/8/10,9/9/-,9/9/12,11/11/-,11/11/12 | |
| Tire | 11.00R20,12.00R20 18PR,12R22.5,295/80R22.5,315/80R22.5 18PR | |
