3 Axles Van Semi-trailer |
||||
|
Main Description |
||||
|
Overall Dimension |
14600mm*2655mm*3900mm |
|||
|
Tare Weight |
11000kg |
Pay Load |
45 ton |
|
|
King Pin Setting |
1460mm |
Rear Overhang |
1930mm |
|
|
Track |
1840mm |
Loading surface height |
1650mm |
|
|
Wheel base |
7800mm+1310mm+1310mm |
|||
|
Box Body Dimension |
14400mm*2500mm*2400mm |
|||
|
Box Body |
Floor steel sheet 3mm, side wall steel sheet 1.5mm |
|||
|
Running Gear |
||||
|
Suspension |
Mechanical suspension with 10-pcs leaf spring |
|||
|
Tires |
315/80R22.5, 13 units. (12R22.5, 12.00R20 are optional) |
|||
|
Axles |
FUWA Brand, 3 axles, load capacity 13T per axle |
|||
|
Brakes |
Dual lines pneumatic brake system; T30/30+T30 air chamber; parking brake |
|||
|
Chassis |
||||
|
Main Beam |
The height of the beam is 520 mm, upper plate is 16mm, down plate is 18mm, middle plate is 10mm |
|||
|
Cross Beam |
Mild Alloy Q235B |
|||
|
King Pin |
Size: 3.5” or 2.0” |
|||
|
Landing Gear |
Single side operation |
|||
|
Electrical & Paint |
||||
|
Lights & Reflectors |
Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light |
|||
|
Wiring |
24V, 6 lines |
|||
|
Air Connector |
ISO standard air connector, 24V 7 pin plug socket |
|||
|
Paint |
Sand blasting before painting, 2 coat of anti-corrosive primer, 2 coats of finish urethane paint, Color upon request |
|||
|
Others |
||||
|
1 Tool Box, 2 Spare Tire Racks |
||||
