Sinotruk Howo dump truck 10 Wheel 6x4 371hp 20 cubic meters
We can supply sinotruk howo dump truck for our clients with good quality and competitive price,
because we get directly support from factory.
Check Blow specificaiton to get your truck
Sinotruk Howo dump truck specificaiton
|
Specifications |
|
|
Model |
30 ton Sinotruk Howo dump truck |
|
Traction |
6X4, |
|
Power |
336HP, 340HP, 371HP, 380HP |
|
Weight Parameter |
|
|
Complete Vehicle Kerb Mass(kg) |
12250 |
|
Maximum authorized total mass (kg) |
30000 |
|
Dimension Parameter |
|
|
External Dimensions(mm) |
8545X2496X 3170 |
|
wheelbase(mm) |
3625+1350 |
|
Internal cargo Sizes |
6000X2300X1500 |
|
Recommended Configuration |
|
|
Engine Type |
WD615.69 |
|
Rated power(kW)/Rev(r/min) |
247/2200 |
|
Transmission |
Manual operation,10 forward & 2reverse with no synchronizer |
|
Front Axle Payload(kg) |
9000 |
|
Rear Axle Payload(kg) |
16000x2 |
|
Fuel Tank(L) |
300 |
|
Track(mm) |
2022+1830 |
|
Front overhang/rear overhang(mm) |
1500/2295 |
|
Tire |
12.00-20 |
|
Cabin |
Standard cab with One sleeper, with 4-point support fully floating suspension and shock absorbers, with air conditioner |
