| General |
Total length (mm) |
8995 |
| Total width (mm) |
2430 |
| Total height (mm) |
330 |
| Wheel base (mm) |
4300 |
| Maximum gross weight (kg) |
12600 |
| Number of passenger (person) |
24-38 |
| Configuration |
Engine |
Engine with MAN Technology |
MC07.28/MC07.24 |
EV Drive system |
Electric control system |
SINONTRUK |
| Rated power (KW) |
206/176 |
Drive motor |
permanent magnet synchronous motor |
| Emission |
Euro III-Euro V |
Rated/Peak power |
80/160 |
| Clutch |
Diaphragm φ395mm thrust |
Battery capacity |
210.5 |
| Transmission box |
6-gear MT |
Cruising (km) |
400 (Uniform speed) |
| Description |
standard |
Optional |
| Axle |
front disc and rear drum |
front disc and rear disc |
| Suspension |
Leaf spring |
Air suspension, imported air spring |
| Heating system |
Defroster |
Independent heating system |
| Air conditioning system |
22,000 kcal |
24,000 kcal |
| Audio-Video system |
MP3 radio player |
HD player + front ceiling 19" fixed LCD display + Microphone |
