Brand

SINOTRUK

Model

ZZ3257N3847A

Cabin

HW76 with single bunk with air conditioner

Driving type:

LHD/RHD

Engine Model

WD615.47

336HP/371HP/420HP

Emssion standard:

Euro 2

Gear box

CNHTC

Max torque:1900NM

Model:

HW19710+HW50/10 speed+2 reverse

Maximum speed (km/h)：

80

Axle(front/rear)

Front axle

VGD95

Tandem

HC16 double reduction hub redactor driving axle

Steering

ZF8118,LHD/RHD is optional with power assistance

Tyre

10+1 spare tyre with rim/12.00R20 radial tyre

Front/Rear

10/12

Inside size of body(mm) : 5800*2300*1500,8mm(floor)*6mm(side),made of high intensity steel

Lifting type : Front lifter, hydraulic system

Overall dimension(mm) : 8545mm*2496mm*3350(Length+width+height)

Fuel tank

300/400L
