Technical Parameter for Sinotruk Howo 8x4 Dump Truck |
||
|
Chassis model: |
ZZ3317V3567 |
|
|
Driving type |
LHD (RHD is optional) |
|
|
SINOTRUK Cabin |
HW 76 Howo new cabin with one sleeper and two seats 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer, with 4-point support fully floating suspension + shock absorber. |
|
|
Engine |
Make: Weichai Power Diesel 4-stroke direct injection diesel engine Model: WP12.400E201 400HP Euro2 cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 11.596L |
|
|
Transmission |
HW19710+HW50(PTO) SINOTRUK GEARBOX 10-forward and 2-reserve speed Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2) |
|
|
Chassis |
Front suspension |
10 semi-elliptic |
|
Rear suspension |
12 leaf semi-elliptic |
|
|
Front Axle |
VGD95 2x9500KGS Steering with double T-cross section beam |
|
|
Rear Axle |
HC16 2x16000KGS Ratio:5.73 Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles. |
|
|
Tires |
315/80R22.5; (12.00R20; 12R22.5; 13R22.5...is optional) with one spare tire 12+1 pieces. |
|
|
Fuel Tank |
300L |
|
|
Cargo Body |
Dimension |
7300*2300*1650 mm |
|
Thickness |
Floor 8mm, Side 6mm |
|
|
Lifting System |
Front Lifting System |
|
|
Loading capacity |
35-50 Tons Howo dump truck for loading sand, coal, bauxite, stones.... |
|
|
Overall Dimension |
10100*2550*3500 mm |
|
|
Color |
White; Yellow; Blue; Orange; Black; Red or others |
|
