Traction type

6x4

Driving type

Left Hand Driving

Overall Dimension(Lx W xH)

6985*2496*3850

Wheel base(mm)

3225+1350

Curb weight(kg)

8800

Front overhang/rear overhang (mm)

1540/845

Approach angle/Departure angle

15/46

Engine

Steyr technology, made in China

WD615.47

Diesel, 4-stoke Direct injection,6-cylinder in

line, radiator, turbo-charging, water-cooling, EGR(Exhausted Gas Recycling)

Displacement(L)

9.726

Bore X stroke (mm)

126mm/130mm

Max power(kw/rpm)

371hp

Max torque(Nm/rpm)

1500NM@1100~1600

Rated speed (rpm)

2200

Min.rate of fuel

consuming

(g/kw.h)

190

Max speed (km/h)

101

Emission

EURO II

Fuel tanker(L)

400 Al fuel tanker

Clutch

Model

D430 diaphragm type

Gearbox

Brand

HW

Model

HW19712

Shift mode

12 forward speeds;

2 reverse speeds

Steering system

Model

ZF8118

Front axle

HR9 9ton front non-driving steering axle

Middle and Rear axle

AC16 16ton single reduction driving axle

Tyre

12.00R20 Radial tire

Number of tyre

10+1 spare

Suspension

Leaf spring type

Fifth wheel

90mm (3.5inch)

Color

Black,Red

Electrical

Battery

2x12V/165Ah

Generator

28V-1500KW

Starter

7.5Kw/24V

Cabin

A7-V cab, two sleepers, with air-conditioner, ABS,

4 point full floating air suspension,adjustable

steering wheel with various heights and angles
