HOWO T7H Concrete Mixer Truck
- Release time：
- Source：Sinotruk HOWO
[HOWO-T7H] ZZ5257GJBV404HD1
It is a new generation high-end heavy truck derived from the MAN assembly, featured with the excellent fuel efficiency, low dead load, high engine force, high reliability, outstanding riding safety and comfort at the world level, completed with multiple customization options. The high serviceability rate makes it a perfect choose for medium and low load organized towing transportation and logistics.
Technical Parameters| Mass Parameter | Curb Weight（kg） | 14170 | |
| Fully-Loaded Mass（kg） | 25000 | ||
| Towable Mass（kg） | ? | ||
| Dimensions | Overall Dimensions | Length（mm） | 10005 |
| Width（mm） | 2496 | ||
| Height（mm） | 3980 | ||
| Wheel Base（mm） | 4025+1350 | ||
| Minimum Ground Clearance（mm） | 313 | ||
| Performance Parameters | Maximum Speed（km/h） | 78 | |
| Economic Speed（km/h） | 50～70 | ||
| Maximum Gradability（%） | ≥45% | ||
| Minimum Turning Diameter（m） | 17 | ||
| Engine | Model | MC11.40-40,MC11.44-40 |
| Net Power（kw）/Rotating Speed（r/min） | 294/1900,324/1900 | |
| Maximum Torque（Nm）/Rotating Speed（r/min） | 1900/1000～1400,2100/1000～1400 | |
| Gearbox | HW19710 | |
| Clutch（mm） | 430 | |
| Rear Axle Type | AC16 | |
| Rear Axle Gear Ratio | 4.77 | |
| Oil Tank（L） | 400 | |
| Chassis Cross Section（mm） | 300*80*8+280*70*8 | |
| Suspension (Frontal & Rear Springs) | 4/-,4/5,9/12 | |
| Tires | 11.00-20,11.00R20 16PR,12.00-20 16PR,12.00R20 14PR | |
