Model No.

ZZ1317N3261W

Engine

371HP(EURO II), 380HP(EURO III), 380HP (EURO IV)

Gear Box

HW19710, 10 forward & 2 reverse

Steering

ZF8118 hydraulic steering with power assistance

Driving Axle

HC16, 16 tons double reduction

Cab

HW76 cab, (one sleeper, with air-condition), all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers.

Wheelbase(mm)

1800 +3200 +1350

Tyre

12.00.R20 Radial tyre,13 units, one spare

Front Axle

HF9 9000Kgs

Displacement

9.726L

Overall dimension (L*W*H)

10150*2496*3950mm

Max speed(km/h)

90

Fuel tanker capacity(L)

300

Color

Red, Green, Blue, Yellow, White etc

Brake system

Service

Dual circuit compressed air brake

Parking

Spring energy, compressed air operating on rear wheels

Auxiliary

Engine exhaust brake

Electrical system

Battery

2X12V/165Ah

Alternator

28V-1500kw

Starter

7.5Kw/24V

Geometric Volume

19m3

Agitating Capacity

12m3

Drum rotating

14°

Agitator rotaion speed

0-14r/min

Feeding speed

>3.5m3/min

Water Tank Volume

400L

Discharge remain ratio

<0.2%
