sinotruk howo dump truck price
- Release time：
- Source：Sinotruk HOWO
sinotruk howo dump truck price
Advantages For 6x4 SINOTRUK HOWO Dump Truck
1. Heavy duty truck chassis sinotruk howo
2. Reinforced body structure with proven telescopic tipping gear,with front lifthing or middle liffting for option.
3. Combination of driving comfort and power
4. Key pressure point reinforced cargo body
5. Robust powertrain can help you handle any challange at the construction site
6. Stable and reliable under-body tipping device ensures low-gravity hoisting
|
Truck Model |
ZZ3257M3647W, LHD ,RHD both available |
||
|
Truck Brand |
SINOTRUK -HOWO |
||
|
Dimension(Lx W xH) |
8145x2496x3386 |
||
|
Cargo body size (L*W*H, mm) |
5400x2300x1400 |
||
|
Cargo body thickness(mm) |
bottom:8mm, side:6mm, or customized as you required |
||
|
Lift type of Carriage |
Ventral lifting |
||
|
Approaching angle/Departure angle(°) |
19/26 |
||
|
Overhang(front/rear) (mm) |
1500/1739 |
||
|
Wheel base (mm) |
3625+1350 |
||
|
Max speed(km/h) |
75 |
||
|
Curb weight(kg) |
11290 |
||
|
Loading Weight(kg) |
25000 |
||
|
Fuel Tanker |
300L with locking fuel cap |
||
|
Fuel consumption(L/100km) |
32 |
||
|
Clutch |
Single-plate dry clutch Φ430mm |
||
|
Engine |
Model |
WD615.87,4- stroke direct injection diesel engine, 6 cylinders in line with water cooling , |
|
|
Horse Power, |
290HP |
||
|
Emission Standard |
EURO II |
||
|
Transmission |
Model |
HW 19710,10 forwards and 2 reverse |
|
|
Brake system |
Service brake |
Dual circuit compressed air brake |
|
|
Parking brake |
spring energy, compressed air operating on rear wheels |
||
|
Auxiliary brake |
Engine exhaust brake |
||
|
Steering system |
Model |
ZF8098/ZF8118 hydraulic steering with power assistance |
|
|
Front axle |
HF9 |
||
|
Rear axle |
HC16 |
||
|
Tire |
12.00R20 |
||
|
Electrical system |
Operating voltage |
24V,negative grounded |
|
|
Starter |
24V,7.35KW |
||
|
Alternator |
28V,1500W |
||
|
Batteries |
2*12V.165Ah |
||
howo dump truck assembly line
howo dump truck body
